Why dryer exhaust is the biggest prize in the mill

Stand at the dry end of any paper machine and look up. The hood above the cylinders is exhausting warm, humid air around the clock, and in most mills a large share of the heat in that stream goes straight to atmosphere. The IEA attributes around 70% of energy use in the pulp and paper sector to drying. That single number explains why, when we audit a mill, the dryer section is where we start and usually where the biggest opportunity sits. The same logic holds in wood panel plants, where the fibre or particle dryer plays the equivalent dominant role in thermal demand.

These are field notes from that work: what the heat load actually is, the order in which to chase it, and the habits that separate a heat recovery project that delivers from one that disappoints.

The size of the prize

On a large modern paper or board machine, the recoverable heat in the exhaust air can exceed 50 MW, equivalent to roughly 86 tonnes of steam per hour. Older and smaller machines carry less, but the exhaust is still typically the largest single heat stream leaving the building. And these are not theoretical numbers. Published rebuilds in the Nordic industry include a mill that cut site energy consumption by 14% with a heat recovery rebuild, achieving payback within a single cold winter, and another that recovered over 11 MW from its exhaust. When supplier case studies and audit findings keep landing in the same range, an engineer can treat the range as real.

Fix the hood balance before you buy exchangers

The most common mistake is starting with exchanger procurement. The cheapest kilowatt hours in the dryer section come from the hood itself: closing or upgrading it, balancing supply and exhaust air, and bringing pocket ventilation under control. Hood and air system measures alone typically cut dryer steam demand by 5 to 15%, before any recovery hardware is installed.

The key variable is exhaust dew point. A leaky, over-ventilated hood discharges huge volumes of barely-humid air; a tight, balanced hood concentrates the same evaporated water into a smaller, wetter stream, with the dew point raised towards 60 to 65 degrees C. That matters twice over. Less air movement means less fan power and less heated make-up air, and a higher dew point means far more condensing duty available to downstream exchangers. One published dew point optimisation increased heat recovery capacity by around 19% without adding a single exchanger surface. Sequence the work accordingly: hood first, recovery second.

What a proper recovery stack looks like

Dryer exhaust heat recovery is a multi-stage system, not a single exchanger. The design question is which heat sinks the mill can actually use, at what temperature, for how many hours a year. A typical stack runs:

• An air-to-air first stage preheating dryer supply air, the highest-grade duty and the one that displaces steam most directly.
• Air-to-water stages heating white water and fresh process water, which carry the recovery through periods when supply air demand is low.
• A final stage serving machine room or building ventilation, sweeping up the low-grade remainder that would otherwise be worthless.

The order matters because exhaust temperature falls through each stage. Put the wrong sink first and the stack underperforms forever. The sizing inputs are measured, not assumed: exhaust flow, temperature and humidity from a hood survey, and a realistic annual profile of each sink. Oversized recovery serving sinks that do not exist on paper is how projects end up delivering half their feasibility number.

The press section is part of the drying story

Before celebrating exhaust recovery, check what is arriving at the dryers in the first place. The commonly cited rule of thumb is that each 1 percentage point of dryness gained after the presses cuts dryer steam demand by roughly 4%. Shoe press upgrades, felt management and nip control are therefore legitimate thermal energy measures, even though they live on the wet end of the energy balance. A mill that improves post-press dryness and then recovers heat from a tighter hood is attacking the same prize from both ends.

Will it hurt moisture control?

This is the first question every machine crew asks, and it is the right one. The honest answer: recovery sits on the exhaust side, downstream of the sheet, and the enabling work, hood balance, dew point control and pocket ventilation, is the same work that stabilises the drying environment. Engineered properly, the cross-direction moisture profile does not degrade, and a steadier hood often removes variability the crew had been managing by running hot. The discipline is to measure the profile before and after commissioning so the debate is settled with data rather than opinion.

Upgrading what is left

After conventional recovery, the exhaust still holds low-grade heat, and so does the mill’s effluent. Mechanical vapour recompression and high temperature heat pumps can lift these streams back to low pressure steam, turning waste heat into header capacity. Whether that stacks up depends on local electricity and carbon prices against fuel costs, so we treat it as a techno-economic screening exercise per site rather than a default recommendation. As carbon costs rise, the screening result keeps shifting in the heat pump’s favour.

Verify it or it did not happen

Every recovery project should be wrapped in measurement. That means sub-metering steam to the dryer groups, tracking specific steam consumption in tonnes of steam per tonne of paper, and building a monitoring and targeting regression baseline before the project so weather and production effects can be separated from genuine savings. We verify results to IPMVP, the same discipline that underpins our energy management work, because a savings claim without a baseline is an anecdote. It is also what keeps savings alive: drift shows up in the data long before it shows up in the fuel bill.

Where to start

Not with capital. A hood balance and dew point survey, normally part of a mill-wide thermal audit, quantifies your machine’s exhaust duty, ranks the hood, press and recovery measures by payback, and gives finance a number it can underwrite. From there, design and project delivery turns the survey into installed hardware inside your planned shutdown windows. The heat is already there, leaving through the roof on every shift. More on how we work with mills and panel plants is at our wood, paper and pulps practice.
